C10D190CG

Online Inquiry

Product number:

C10D190CG

Product description:

Designed for high-end luxury building projects, this Champagne Gold Finish BIPV module blends elegant and sophisticated aesthetic design with reliable photovoltaic performance, an ideal choice for luxury residential communities, high-end commercial plazas and boutique office buildings pursuing high-quality architectural taste and clean energy utilization.

Core Selling Points:

✅ Luxury Architectural Aesthetic Compatibility

Elegant champagne gold finish elevates the luxury and high-end texture of buildings, perfectly matching high-end residential, boutique commercial and premium office architectural styles; 6mm double-sided tempered glass maintains the luster and color stability of the champagne gold finish for a long time, enabling seamless integration into high-end building facades, decorative curtain walls and rooftop gardens without sacrificing design aesthetics.

✅ Reliable Steady Power Generation

Delivers tailored energy performance for high-end projects with 190W STC-rated peak power and a 11.9% module efficiency; under NOCT real working conditions, the peak power is 176W, with a -0.38%/℃ Pmax temperature coefficient ensuring stable power output in temperature fluctuations. Equipped with 40 premium 182PERC cells to guarantee consistent and reliable photoelectric conversion for high-end building daily energy demand.

✅ Premium Grade Environmental Durability

Built to the high durability standards of luxury buildings: -40℃ to +85℃ wide operating temperature range adapts to various regional climates, 5400Pa front/back maximum static load for wind, snow and pressure resistance; IP67-rated junction box with excellent waterproof and dustproof performance, Class II safety protection level and Class A fire rating, fully meeting the strict safety and durability requirements of high-end building projects.

✅ Adaptable High-End Project Installation

1600×1000×14mm optimized dimensions and 56kg weight fit the delicate profile requirements of high-end buildings; standard MC4 connectors enable seamless connection with high-end solar energy systems, 4mm² 300mm standard cables or customizable specifications adapt to the personalized installation needs of luxury building facades and decorative curtain walls, ensuring the perfection of the building's overall design during installation.

Explore the detailed technical specifications below to learn more about how this champagne gold finish BIPV module integrates luxury design and clean energy for your high-end building project.

**Electrical Specification[STC*]**
STC	Standard Test Conditions: Irradiation 1000W/m², Cell Temperature 25℃, AM1.5
Color	Champagne Gold
Rated Maximum Power(Pmax/W)	190
Power Tolerance	5%
Maximum Power Voltage(Vmp/V)	46.8
Maximum Power Current(lmp/A)	4.06
Open Circuit Voltage(Voc/V)	54.8
Short Circuit Current(lsc/A)	4.25
Module Efficiency[%]	11.9%

**Electrical Specification[NOCT*]**
NOCT	Normal Operating Cell Temperature（NOCT）：800W/㎡，20℃，AM1.5，1m/s
Color	Champagne Gold
Rated Maximum Power(Pmax/W)	176
Maximum Power Voltage(Vmp/V)	43.4
Maximum Power Current(lmp/A)	4.12
Open Circuit Voltage(Voc/V)	50.85
Short Circuit Current(lsc/A)	4.31

**Mechanical parameters**
Dimensions（mm)	1600100014
Weight(kg)	56
Cell	182PERC
Number of cells	40
Front Glass（mm）	6
Back Glass（mm）	6
Junction Box	IP67
Connector	MC4
Cable Specifications	4mm²，300mm,Customization available
Packing Quantity	/
